170F Engine, 2.0KW Power Generating output.
UNIQUE FEATURES:
- Carbin creatively combines Power Generation into the Engine;
- DEI Gasoline Generator is providing Mechanical Energy and Electrical Energy at the same time.
- 170F Engine, 2.0KW Power Generating output.
|
Engine |
Model |
DEI 170F |
|
Engine Type |
Single Cylinder, Air Cooling, 4-Stroke, Horizontal Shaft |
|
|
Bore×Stroke |
70 × 54 mm |
|
|
Displacement |
208 CC |
|
|
Compression Ratio |
8.2 : 1 |
|
|
Max Engine Speed |
3600 rpm |
|
|
Max Power Output |
7.0/3600 hp/rpm |
|
|
Max Torque |
13.5/3000 N·m/rpm |
|
|
Fuel Supply Mode |
Carburetor |
|
|
Starting Mode |
Recoil |
|
|
Ignition System |
TCI |
|
|
Fuel Tank Capacity |
5.2 L |
|
|
Oil Capacity |
0.6 L |
|
|
Oil Alert |
Oil Alert Protection |
|
|
Noise Level dB/7m |
67 dB/7m |
|
|
Power |
Rated Power |
2.0 KW |
|
Frequency |
50Hz / 60Hz |
|
|
Voltage |
220V / 110V |
|
|
Packing |
Gross/Net Weight |
19 / 18 Kg |
|
Packing Size L×W×H |
390 × 340 × 385 mm |
|
|
Container Load Q'ty |
504 sets/20GP |
