Gasoline welding Generator for simultaneous operation of 2.5-5.0mm electrode welding and 3.0KW AC output
| 体积小 | Small size |
| 重量轻55kg | Light weight - 55kg |
| 轻巧便携 | Quite portable |
| 发电输出3.0KW交流电 | 3.0KW AC output |
| 纯正弦波电流，变频稳压 | Pure sine wave output, stable and reliable voltage by inverter |
| 动力为192F升级版，更强劲，做到发电也大，焊接也大，更稳定 | More powerful and stable upgraded 192F engine brings stronger and more stable power output and welding |
| 焊接发电可同时使用 | Welding and power generation can be |
| 最大可用5.0焊条 | Can use up to 5.0mm electrode |
| 一机多能方便简单 | One mac hine for multiple uses, convenient and simple |
| 电流大小可任意调节 | The current is adjustable freely |
| 省油节能 | Fuel/energy saving |
| 型号 Model |
GF 9000-300 |
| 燃油 Fuel |
汽油 Gasoline |
| 焊接方式 Welding Mode |
手弧焊 Manual Welding |
| 焊接电流 Welding Current |
80A-300A, 可调节 adjustable |
| 空载电压 No Load Voltage |
55 - 72 V |
| 焊接电压 Welding Voltage |
25.6 - 72 V |
| 持续工作效率 Continued Load Running Rate |
60% |
| 焊条直径 Welding Electrode Size |
2.5-5.0 mm |
| 辅助发电输出功率 Auxiliary Power Output |
3.0 KW 交流 AC |
| 发动机 Engine Model |
190F |
| 缸径 x 行程 Bore x Stroke |
90×66 mm |
| 启动方式 Starting System |
420 cc |
| 排量 Displacement |
手启动 Recoil |
| 燃油/机油容量 Fuel / Oil Capacity |
12.0/1.1 L |
| 毛重/净重 Gross / Net Weight |
68.0/66.0 KGS |
| 外形尺寸 (长x宽x高) Dimensions L × W × H |
520×540×600 mm |
| 包装尺寸 (长x宽x高) Packing Size L × W × H |
560×560×620 mm |
| 装柜数量 Container Load Q'ty |
120 pcs, 20GP 336 pcs, 40HQ |
